MICOE High COP EVI Technology Air Source Heat Pump Floor Heating and Cooling New Energy Heat Pump
Product Description
MICOE EVI Heat Pump is specially designed for heating and cooling. With EVI technology, this kind of Heat Pump
can work very well in cold area such as -25℃. Using free renewable energy from the air, the heat pump is highly
efficient with low cost. It can save energy up to 80% compared with traditional water heaters.
Features&Benefits
EVI technology, -25℃ working
Heating & Cooling
High efficiency with good performance
Famous brand EVI compressor with R410a
Enlarged heat exchangers, high COP
Whisper quiet fan
Intelligent controller
Reverse cycle defrost with 4-way valve
Hydrophilic fin coil coating
Operation protection included
100% factory tested
| DATA SHEET | ||||||
| Heat Pump Warer Heater /Heating and Cooling / Residential Series | ||||||
| Model No. | MHP-004A1 | MHP-006A1 | MHP-008A1 | MHP-010A1 | MHP-012A1 | MHP-018A1 |
| Power Supply | 220V/1/50Hz | 380V/3/50Hz | ||||
| Text Condition : Heating Capacity at Air 20℃/15℃, Water Temperature From 15℃ to 55 ℃ | ||||||
| Heating Capacity(kW) | 3.6 | 5.4 | 7.6 | 10.8 | 13.2 | 18.8 |
| Power Input(kW) | 0.86 | 1.26 | 1.81 | 2.54 | 3.17 | 4.56 |
| COP | 4.19 | 4.29 | 4.20 | 4.25 | 4.16 | 4.12 |
| Max Power Input(kW) | 1.45 | 2.01 | 2.75 | 3.02 | 4.51 | 6.02 |
| Max Current(A) | 6.5 | 9.0 | 12.0 | 15.2 | 23.0 | 11.0 |
| Refrigerant | R410a | R410a | R410a | R410a | R410a | R410a |
| Expansion Valve | Electronic | |||||
| Air Flow Direction | Horizotal | Horizotal | Horizotal | Horizotal | Horizotal | Horizotal |
| Water Pressure Drop(Kpa) | 35.0 | 35.0 | 40.0 | 45.0 | 45.0 | 45.0 |
| Net Dimensions(L*W*H)(mm) | 936×385×550 | 956×420×614 | 986×420×798 | 1003×375×1320 | ||
| Package Dimensions(L*W*H)(mm) | 1055×445×592 | 1066×480×657 | 1115×490×930 | 1070×445×1440 | ||
| Working temperature range(℃) | -15~43 | -15~43 | -15~43 | -15~43 | -15~43 | -15~43 |
| Noise(dB) | 47 | 49 | 50 | 52 | 52 | 54 |
| Water connection(mm) | 20 | 20 | 20 | 20 | 20 | 20 |
